SPECIFICATION COMPLIANCE:

Complies to standard IS/IEC 60529:2001(RA2019) (Empty Enclosure, Control Instrument)

CERTIFICATION COMPLIANCE:

KLPL/BTC/22/05-07 (IP-55, IP-65) TUV/PTL/22-23/SFTY-WT/0018 (IP-55, IP-65)

DESIGN SPECIFICATION:

Removable front and back door, fully welded structure of panels, Top removable or fixed welded by ensuring Ingress Protection is maintained, all accessories are removable in design.

MATERIAL:

Body, Doors, Structure 1.6mm, 2mm, 2.5mm, 3 mm in 316,3161, 304,304L material standard, Finish 2B/N4 Matt,

STANDARD FEATURES:

Enclosures fitted as standard with 304,316,316L locks, hinges, door stopper, drain breather, drawing pocket, light bracket and limit switch bracket, Farthing studs, and hardware.

EARTHING PROVISION:

LHS side, copper earth stud available from inside and outside the Enclosure.

CONSTRUCTION:

Fully welded, rigid and robust frame.

DOORS:

Fitted with hinged LHS or RHS openings. Removable type with Screw and Bush fitting.

LOCK:

Single-point CAM lock with Key, 3-point Swing handle with Key, Push button handle with Key.

CABLE ENTRY ARRANGEMENT:

Removable Gland plate from inside or outside of the enclosure in 2-6mm thickness in SS Material standard.

LIFTING ARRANGEMENT:

Removable I-Bolt M-12 size with 200 kg each load carrying capacity fitted with a bush arrangement

PLINTH/STAND:

Removable Plinth of size 100mm-300mm with grounding provision, fully welded stand with square tube as per 100mm-400mm as per application.

FINISH:

Inside 2-B, Outside N-4 (Matt)
